Deep Groove Ball Bearings 6400 Series OPEN/ZZ/2RS/2RZ Z2,V2,Z3,V3,Z4,V4

Deep Groove Ball Bearings 6400 Series OPEN/ZZ/2RS/2RZ Z2,V2,Z3,V3

Key Feature

CSC can produce high quality DGBB as the customer requests.We are happy to produce further construction methods. Please do not hesitate to contact us for special bearing characters

Product Specification

Bearing No.						Boundary Dimensions(mm)						Basic Load Rating(kN)		Weight(kg)
Standard type	Non-standard type					d	D	B	r_{s min}	D2(max)	f(max)	Cr	Cor
Standard type	Shield	Seal		With snap ring groove	With snap ring	d	D	B	r_{s min}	D2(max)	f(max)	Cr	Cor
6405	——	——	——	N	NR	25	80	21	1.5	86.6	1.7	35.8	19.3	0.530
6406	——	——	——	N	NR	30	90	23	1.5	96.5	2.46	43.6	23.6	0.738
6407	——	——	——	N	NR	35	100	25	1.5	106.5	2.46	55.3	31	0.951
6408	——	——	——	N	NR	40	110	27	2	116.6	2.46	63.7	36.5	1.250
6409	——	——	——	N	NR	45	120	29	2	129.7	2.82	76.1	45	1.550
6410	——	——	——	N	NR	50	130	31	2.1	139.7	2.82	87.1	52	1.900
6411	——	——	——	N	NR	55	140	33	2.1	149.7	2.82	99.5	62	2.300
6412	——	——	——	N	NR	60	150	35	2.1	159.7	2.82	114	70.1	2.730
6413	——	——	——	N	NR	65	160	37	2.1	169.7	2.82	119	78	3.300
6414	——	——	——	N	NR	70	180	42	3	192.9	3.1	143	104	4.850
6415	——	——	——	N	NR	75	190	45	3	202.9	3.1	153	114	6.800
6416	——	——	——	N	NR	80	200	48	3	212.9	3.1	163	125	8.000
6417	——	——	——	N	NR	85	210	52	4	222.8	3.1	174	134	9.500
6418	——	——	——	N	NR	90	225	54	4	237	3.5	186	146	11.500

Precision Rate	P0,P6,P5,ABEC 1,ABEC 3,ABEC 5
Vrbration	Z1,Z2,Z3,Z4,V1,V2,V3,V4
Bore Size	10mm-200mm
Cage	Steel Retainer,Nylon Retainer
Seal Type	Open,2RS,ZZ,2RSE,2RZ,N,NR,RS,Z
Lubricated	Oil,Grease
Clearance	C0,C2,C3,C4,C5

Application

Logistic Transport Facilities
Automation Technology
Machine Tools
Aerospace Industry
Mechanical Engineering
Industrial Robots
Textile Machinery
Automotive Industry
Construction Machinery
Electric Motors
Gearboxes

Selection of Bearings

Our team of specialists from the German rolling bearing industry supports you by stress analyzes and calculations in the selection of the right bearings.

Stress Analyzes
Storage and Durability Calculations
Design Advice for "Non-standard bearings"
Selection of Greasing
Quality Analysis
Damage Analysis
